M-252 Dry System Shotcrete Machine

M-252 DRY SYSTEM SHOTCRETE MACHINE
Refractory concrete spraying machine, double speed motor and without the possibility of using electronics part. In case of malfunction, the ability to identify easily and quickly.
AREAS OF APPLICATION
Tunnel, underground works, after excavation the soil of support, retaining wall, pools, storage tank, building surfaces of different structures, bridge, port, repair and restoration of dams, strengthening buildings against earthqakes, the melting pot and useable filing process.

M 252 MACHINE A PROJETER (REFRACTAIRE)

Rotary Capacity

4 / 7 Liters

Cocrete Tranfer Capacity

2 – 4 m3 / h (2.6/5.2yd3)

Concrete Delivery Hose Dimension

1 ½ “ 40 bar – 2” 40 bar

Spraying Air Pressure

5-9 bar (70 – 130 PSI)

Spraying Air Flow

5-12 m3 / min (200-420 cfm)

Aggregate Measure

12 mm Max.

Dry Mix Range

Horizontal 300 Meters / Vertical 100 Meters

Weight

525 Kg.

Dimensions

W : 580 mm. /  H : 1200 mm. / L : 1200 mm.
